Data Structures
union	value_pair_data

struct	value_pair

Typedefs
typedef union value_pair_data	VALUE_PAIR_DATA

typedef struct value_pair	VALUE_PAIR

Functions
VALUE_PAIR *	nr_vp_alloc (const DICT_ATTR *da)

void	nr_vp_free (VALUE_PAIR **head)

VALUE_PAIR *	nr_vp_init (VALUE_PAIR vp, const DICT_ATTR da)

VALUE_PAIR *	nr_vp_alloc_raw (unsigned int attr, unsigned int vendor)

int	nr_vp_set_data (VALUE_PAIR vp, const void data, size_t data_len)

int	nr_vp_set_raw_data (VALUE_PAIR vp, const void data, size_t data_len)

VALUE_PAIR *	nr_vp_create (int attr, int vendor, const void *data, size_t data_len)

void	nr_vps_append (VALUE_PAIR *head, VALUE_PAIR vp)

VALUE_PAIR *	nr_vps_find (VALUE_PAIR *head, unsigned int attr, unsigned int vendor)

Detailed Description

These routines manage structures which map to attributes.

Typedef Documentation

typedef struct value_pair VALUE_PAIR

C structure version of a RADIUS attribute.

The library APIs use this structure to avoid depending on the details of the protocol.

typedef union value_pair_data VALUE_PAIR_DATA

Union holding all possible types of data for a VALUE_PAIR.

Function Documentation

VALUE_PAIR* nr_vp_alloc ( const DICT_ATTR * da )

Allocate a VALUE_PAIR which refers to a DICT_ATTR.

This returned VALUE_PAIR has no data associated with it. The nr_vp_set_data() function must be called before placing the VALUE_PAIR in a RADIUS_PACKET.

Parameters

[in] da The DICT_ATTR associated with the VALUE_PAIR

Returns: The created VALUE_PAIR, or NULL on error.

References nr_strerror_printf(), and nr_vp_init().

Referenced by nr_vp_create(), and nr_vp_sscanf().

Here is the call graph for this function:

VALUE_PAIR* nr_vp_alloc_raw	(	unsigned int	attr,
		unsigned int	vendor
	)

Allocate a VALUE_PAIR which refers to an unknown attribute.

It is used when an attribute is received, and that attribute does not exist in the dictionaries.

The returned VALUE_PAIR has no data (i.e. VALUE_PAIR::length is zero). The nr_vp_set_data() function must be called before placing the VALUE_PAIR in a RADIUS_PACKET.

Parameters

[in]	attr	The attribute number, 0..2^16
[in]	vendor	The vendor number, 0..2^16

Returns: The created VALUE_PAIR, or NULL on error.

References da, nr_dict_attr_2struct(), and nr_strerror_printf().

Here is the call graph for this function:

VALUE_PAIR* nr_vp_create	(	int	attr,
		int	vendor,
		const void *	data,
		size_t	data_len
	)

Create a VALUE_PAIR and set its data.

Parameters

[in]	attr	The attribute number of the VALUE_PAIR to create
[in]	vendor	The vendor number of the VALUE_PAIR to create
[in]	data	Data to set inside of the VALUE_PAIR
[in]	data_len	Length of the data field

Returns: The created VALUE_PAIR, or NULL on error.

References nr_dict_attr_byvalue(), nr_vp_alloc(), nr_vp_free(), and nr_vp_set_data().

Here is the call graph for this function:

void nr_vp_free ( VALUE_PAIR ** head )

Free a VALUE_PAIR.

This function frees the VALUE_PAIR, and sets the head pointer to NULL. If head refers to a VALUE_PAIR list, then all of the structures in the list are freed.

Parameters

[in,out] head The pointer to a VALUE_PAIR, or a VALUE_PAIR list.

References da, attr_flags::encrypt, nr_dict_attr::flags, and next.

Referenced by main(), nr_attr2vp_vsa(), nr_packet_decode(), nr_track_id_packet_free(), nr_vp_create(), and nr_vp_sscanf().

VALUE_PAIR* nr_vp_init	(	VALUE_PAIR *	vp,
		const DICT_ATTR *	da
	)

Initializes a VALUE_PAIR from a DICT_ATTR

This function assumes that the VALUE_PAIR points to existing and writable memory.

Parameters

[in,out]	vp	The VALUE_PAIR to be initialized
[in]	da	The DICT_ATTR used to initialize the VALUE_PAIR

Returns: The initialized VALUE_PAIR, or NULL on error.

References da, nr_dict_attr::flags, attr_flags::length, and length.

Referenced by nr_packet_attr_append(), and nr_vp_alloc().

int nr_vp_set_data	(	VALUE_PAIR *	vp,
		const void *	data,
		size_t	data_len
	)

Set the data associated with a previously allocated VALUE_PAIR.

The data (e.g. integers) is in host byte order. This function should be called by an application when converting application data to VALUE_PAIR structures.

If this function succeeds, VALUE_PAIR::length is no longer zero, and the structure contains the data.

Parameters

[in,out]	vp	The VALUE_PAIR to update
[in]	data	Data to set inside of the VALUE_PAIR
[in]	data_len	Length of the data field

Returns: <0 on error, 0 for "data was truncated" >0 for "data successfully added"

References da, length, NR_TYPE_BYTE, NR_TYPE_DATE, NR_TYPE_INTEGER, NR_TYPE_IPADDR, NR_TYPE_OCTETS, NR_TYPE_SHORT, NR_TYPE_STRING, return_NR_ERR, and nr_dict_attr::type.

Referenced by nr_packet_attr_append(), nr_vp_create(), and nr_vp_set_raw_data().

int nr_vp_set_raw_data	(	VALUE_PAIR *	vp,
		const void *	data,
		size_t	data_len
	)

Set the data associated with a previously allocated VALUE_PAIR.

The data (e.g. integers) is in network byte order. This function should be called when converting raw RADIUS packets to VALUE_PAIR structures. Most applications will not need to call this function.

If this function succeeds, VALUE_PAIR::length is no longer zero, and the structure contains the data.

Parameters

[in,out]	vp	The VALUE_PAIR to update
[in]	data	Data to set inside of the VALUE_PAIR
[in]	data_len	Length of the data field

Returns: <0 on error, 0 for "data was truncated" >0 for "data successfully added"

References da, NR_TYPE_DATE, NR_TYPE_INTEGER, NR_TYPE_IPADDR, NR_TYPE_SHORT, nr_vp_set_data(), return_NR_ERR, and nr_dict_attr::type.

Here is the call graph for this function:

void nr_vps_append	(	VALUE_PAIR **	head,
		VALUE_PAIR *	vp
	)

Append a VALUE_PAIR to the end of a VALUE_PAIR list.

Parameters

[in,out]	head	The head of the VALUE_PAIR list. May not be NULL.
[in]	vp	The VALUE_PAIR to append to the list.

VALUE_PAIR* nr_vps_find	(	VALUE_PAIR *	head,
		unsigned int	attr,
		unsigned int	vendor
	)

Search a VALUE_PAIR list for one of a given number.

Parameters

[in]	head	The head of the VALUE_PAIR list to search.
[in]	attr	The attribute number of the VALUE_PAIR to find
[in]	vendor	The vendor number of the VALUE_PAIR to find

Returns: The found VALUE_PAIR, or NULL if it was not found.

References nr_dict_attr::attr, da, next, and nr_dict_attr::vendor.
